Double Adjustable Carbureted Regulator for Belt Drive Fuel Pump.
Revolutionary design provides two independent pressure adjustments; one adjustment for idle and one for wide open throttle. Engineered for use with variable volume pumps tied to engine RPM. This regulator creates the smoothest and most repeatable fuel curve from idle to wide open throttle of any bypass system. ORB-10 return port. P/N 13209 provides (1) ORB-08 inlet and (3) ORB-08 outlet ports. Can be configured for single or dual carbureted engines and provides superior pressure control and flow when installed before the carburetor or after a fuel log. Also available with a single inlet port for fuel logs. (P/N 13214) provides ORB-10 inlet and return ports.
Revolutionary design provides two independent pressure adjustments; one adjustment for idle and one for wide open throttle. Engineered for use with variable volume pumps tied to engine RPM. This regulator creates the smoothest and most repeatable fuel curve from idle to wide open throttle of any bypass system. ORB-10 return port. P/N 13209 provides (1) ORB-08 inlet and (3) ORB-08 outlet ports. Can be configured for single or dual carbureted engines and provides superior pressure control and flow when installed before the carburetor or after a fuel log. Also available with a single inlet port for fuel logs. (P/N 13214) provides ORB-10 inlet and return ports.
Information:
double adjustable bypass 4-port regulator; works with single and dual carbureted engines; has two independent pressure adjustments: one for idle and one for wide open throttle| Attributes | |
| Fuel Delivery Type | Carburation |
| Gauge Included | No |
| Inlet Gender | Female |
| Inlet Gender.1 | Female |
| Minimum Pressure | 3 |
| Return Port Diameter | ORB-10 |
| Return Port Gender | Female |
| Vacuum/Boost Port | Yes |
| GTIN | 00684980002386 |
